Wait for the “Done uploading” message in the bottom blue status bar.

Upload the sketch: File > Upload to I/O Board.

ARDUINO MEGA 2560 R3 DRIVER BOARD SERIAL

If you do not know which one this is, you can find out by going into Device Manager > Ports (COM & LPT), and look for a “USB Serial Port (COMx)” This is the serial port for the board’s built-in FTDI.

Select the serial port: Tools > Serial Port.

Select the Mega 2560 board: Tools > Board > Arduino Mega 2560.

Open the LED blink sketch: File menu > Examples > Basics > Blink.

You should now see the LED labeled ON near the reset button light up.

“C:\arduino-0022\drivers\FTDI USB Drivers”

If your computer prompts for drivers, point it to the “drivers\FTDI USB Drivers” subfolder of the Arduino software, e.g.

Connect the other end of the cable into a USB port on your PC/Mac.

Connect the USB-B end of the cable into the board.

ARDUINO MEGA 2560 R3 DRIVER BOARD ZIP FILE

Unzip the zip file to somewhere like C:\ (on Windows), so you will end up with a folder like C:\arduino-0022.

ARDUINO MEGA 2560 R3 DRIVER BOARD SOFTWARE

Get the Arduino software if you have not already.

Downloads: OSEPP™ Mega 2560 Schematic (PDF) The Creative Commons Attribution Share-Alike License. This board is based off of the Arduino Mega 2560 designed by Arduino, and is released under The input and/or output pins are brought out to headers which enable a convenient way to prototype projects without the need of soldering or desoldering. To prevent damage to the computer’s USB port, the fuse will trip when the current to the port exceeds 500 mA. There is an ICSP (In-Circuit Serial Programming) header for the ATmega2560 to optionally replace the bootloader.Īs an added precaution, the board comes with a resettable polyfuse on the USB connection path. The ATmega2560 comes with the Arduino bootloader preloaded.

Compatible with the Ethernet and Motor Controller Shields.

Compatible with existing Arduino software libraries.

ICSP header for programming microcontroller.

Flexible power source (USB or DC power).

Connects to a computer via a standard USB cable.

8x more flash and 4x more SRAM and EEPROM than the Uno.

8-bit AVR RISC-based microcontroller running at 16 MHz.Added Molex connector for easy connect to OSEPP™ sensors and other I2C devices.Ĥ.23 x 2.13 x 0.61 inches (107.5 x 54.0 x 15.5 mm).Replaced USB-B connector with more popular mini-USB connector.

This board is perfect for projects that require a lot of inputs/outputs or that require more complex programs that cannot fit into the smaller memory of the ATmega328P.

ARDUINO MEGA 2560 R3 DRIVER BOARD PLUS

The OSEPP™ Mega 2560 R3 Plus is the bigger brother to the OSEPP™ Uno board with more flash memory, more SRAM, more EEPROM, and more pins. Production for the MEGA 2560 has ceased as of June 2016. Then either you made a wiring error, or the chip is bad.The MEGA 2560 is legacy hardware. If you see something like Atmega chip detector.įailed to enter programming mode. At least it responds to programming commands. If you see something like that, the chip is (probably) good. My board had a ATmega8U2 on it, yours might have a ATmega16U2. Using the Serial Monitor on your Uno, you should then see something like this: Atmega chip detector.Ĭompiled on at 10:47:47 with Arduino IDE 106.Īttempting to enter ICSP programming mode. In that case you probably have a cheap clone board. If you have something totally different this will not work. Important! Only attempt this process if you can see that you have an ATmega8U2 or ATmega16U2 chip on your board (see below). Wire the Uno to the chip being tested as follows: Arduino Uno Target chipĬheck your wiring! If you wire things around the wrong way you can turn a good chip into a bad one.

On the board pin 1, has a small white dot.īelow are the ICSP pin names, seen from above (component side). I have circled the correct header pins, and pointed to pin 1. a Uno) to detect the signature on that chip, as per my sketch on Sketch to detect Atmega chip types.Īll you need is 6 hookup wires to connect your testing board (the known good one with the sketch on it) to the ICSP header on the Mega. If your Mega has an ICSP header for the USB chip (circled below) then you can test that chip.
